1. Unwind and Rewind:Tilting the double location,receiving and replacing material without stopping the machine
2. Printing:360 degrees adjustment gear box, with guide roller fine-tuning Don't stop registration devicemovable type doctor blade ,transverse reciprocating motion(optional pressure roller blades and all adopt pneumatic)
3. Dry oven:Double oven, conjoined twins oven(adopted the company patent technology), centrifugal big fan
| Main Technical Parameters |
| Model | ASY-B600 | ASY-B800 | ASY-B1000 | ASY-B1200 |
| Printing colors | 6 (user can increase or decrease) |
| Diameter of printing cylinder | 100-320mm |
| Max.printing width | 600mm | 800mm | 1000mm | 1200mm |
| Diameter of unwind/rewind | 500mm |
| Machine printing speed | 70m/min |
| Max.printing speed | 50m/min |
| Register precision | ±0.25mm |
| Drying method | Electric heating and steam heating or oil heating |
| main power | 20kw | 20kw | 22kw | 24kw |
| Overall dimension | 8800*1200*1700mm | 8800*1200*1700mm | 8800*1200*1700mm | 8800*1200*1700mm |
